HOLLOW BAR

Sizes
1.750" to 6" OD  Walls .188" to 1.500"
Special Sizes
(15,000 lbs. Min. Qty.)
6" to 8" OD  Walls .300 to 2.000"
(and extra long lengths)
HOLLOW BILLET

(Maximum Length 27")
5.500" to 9" OD  Walls 2.000" 3.500"

GRADES
304/304L, 316/316L, Other Stainless Steels, Alloy, Nickel Alloy and Carbon Grades

SPECIFICATIONS
(Stainless)
Mechanical Tubing (Hollow Bar) - R/L's  A-511
>3" = OD +/- .031  Walls +/- 12 1/2%
<3" = OD +/- .023  Walls +/- 12 1/2%

(Carbon)
Carbon Hollow Bar Per A-519

STAINLESS STEEL

The following table provides examples of OD's and Walls which produce various lengths. The OD size ranges are from 1.75" to 6". Above 6" through 8" a minimum order quantity of 15,000 lbs. is required. If longer lengths are required on sizes below 6", a minimum order quantity of 15,000 lbs. is required. Substantially longer lengths can be provided.

OD SIZE WALL
RANGE
LENGTH
1.750" .250 24 - 28 FT
2.750" .300 - .350 20 - 24 FT
2.875" .300 - .425 18 - 22 FT
3.000" .300 - .475 12 - 23 FT
3.250" .300 - .625 12 - 22 FT
3.500" .300 - .750 11 - 21 FT
3.750" .300 - .750 11 - 24 FT
4.000" .300 - .750 11 - 24 FT
4.250" .300 - .750 11 - 27 FT
4.750 .300 - .750 12 - 19 FT
5.000" .300 - .750 12 - 18 FT
5.250" .300 - .750 11 - 18 FT
5.500" .300 - .750 10 - 19 FT
6.000" .300 - .750 10 - 18 FT

Grades: 304, 304L, 316, 316L, 321, 347, 410/403, 405 and 418

Specifications: A182, A276, A479, A312 and A511

How to calculate Weight Per Foot: (OD - Wall) X Wall X 10.68 lbs. = lbs./ft.

EXAMPLES:
1. 2.750" - .300" x .300" x 10.68 lbs. = 7.8 lbs. Per Foot
2. 2.750" - .325" x .325" x 10.68 lbs = 8.42 lbs. Per Foot

Pipe Sizes
